Electric Hydraulic Pipe Bending Machine
Electric Hydraulic Pipe Bending Machine
We provide high-quality electric hydraulic pipe bending machines at a reasonable cost. These machines harness the power of a hydraulic system to bend the pipes along with the electric control system to fine-tune the bending angles with accuracy. It has a user-friendly interface and can be operated more efficiently. It is your go-to solution for precision pipe bending.
- Economical and better effective as it combines the power of both forces - electrical and hydraulic for bending pipes with accuracy.
Technical Specifications
|
|
|||
|---|---|---|---|
|
Model No.
|
SEHPB-2
|
SEHPB-3
|
SEHPB-4
|
|
Capacity (T)
|
13
|
20
|
23
|
|
Maximum Stroke (mm)
|
250
|
290
|
370
|
|
Bending Range (mm)
|
21.5 ~ 60
|
21.5 ~ 88.5
|
21.5 ~108
|
|
Bending Formers (inch)
|
1'2", 3'4", 1", 11'4", 11'2", 2"
|
1'2", 3'4", 1", 11'4", 11'2", 2", 21'2", 3"
|
1'2", 3'4", 1", 11'4", 11'2", 2", 21'2", 3", 4"
|
|
Wall Thickness of Pipe (mm)
|
2.75 - 4.5
|
2.75 - 5
|
2.75 - 6
|
|
G. W.(Kg)
|
74
|
126
|
174
|
|
Volume (mm)
|
960 x 350 x 270
|
1180 x 460 x 270
|
1180 x 460 x 320
|
Features :
- Handy and Economical.
- High Speed and Accuracy.
- They are robust and perform heavy duty pipe and tube bending.
- They are suitable for high production volumes and high pressure bending.
- In this machine, electric Motor is used to pump hydraulic fluid which performs the bending action.
- Available with pre-stressed corner brackets, pre-bend release knob and many other advanced features that add to its operational efficiency.
- They can bend small and large diameter pipes with great accuracy and precision. To produce different types of bend, various tools and dies are used.
Applications :
- Construction
- Brass Industries
- Plastic Industries
- Textile Industries
- Automotive Industries
- Iron Working Industries
- Furniture and Workshop
- Metal Bar Bending Industries
- Sheet Metal Bending Industries
